RoHS
/
Package 12-SIP SMD Module
Category Power Supplies - Board Mount / DC DC Converters
Description REGULATOR 5V 2A HSMD HZ HT
PDF
/
Inventory: 1755
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Physical

Mount Surface Mount
Mounting Type Surface Mount
Package / Case 12-SIP SMD Module

Technical

Operating Temperature -40°C~85°C
Packaging Tray
Series PT6220
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 12
ECCN Code EAR99
Type Non-Isolated PoL Module
Applications ITE (Commercial)
Max Power Dissipation 10W
Terminal Position DUAL
Terminal Form THROUGH-HOLE
Number of Functions 1
Base Part Number PT6222
Pin Count 12
Number of Outputs 1
Qualification Status Not Qualified
Efficiency 89%
Voltage - Input (Max) 38V
Max Output Current 2A
Voltage - Output 1 5V
Voltage - Input (Min) 7V
Input Voltage-Nom 9V
Switcher Configuration BUCK
Switching Frequency-Max 900kHz

Dimensions

Height 17mm
Length 59.9mm
Width 9.65mm

Compliance

RoHS Status Non-RoHS Compliant
Lead Free Contains Lead
