PT6216P
RoHS
RoHS compliant
RoHS compliantPackage 12-SIP Module
Category Power Supplies - Board Mount / DC DC Converters
Description
DC/DC Converters 1.5Vout 2A Wide Inpt Adj Step-Down ISR
PDF
/
Inventory: 5739
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Technical
Output Voltage 1.5V
Max Output Current 2A
Voltage - Input (Min) 9V
Input Voltage-Nom 9V
Control Mode VOLTAGE-MODE
Switcher Configuration BUCK
Switching Frequency-Max 500kHz
Voltage - Input (Max) 17V
Efficiency 72%
Qualification Status Not Qualified
Number of Outputs 1
Pin Count 12
Base Part Number PT6216
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Number of Functions 1
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Position SINGLE
Technology HYBRID
Max Power Dissipation 3W
Subcategory Switching Regulator or Controllers
Applications ITE (Commercial)
Type Non-Isolated PoL Module
ECCN Code EAR99
Number of Terminations 12
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code yes
Series PT6210
Packaging Tray
Operating Temperature -40°C~85°C
Dimensions
Height 17mm
Length 43.4mm
Width 9.65mm
Compliance
RoHS Status ROHS3 Compliant
Lead Free Lead Free
Physical
Number of Pins 12
Package / Case 12-SIP Module
Mounting Type Through Hole
Mount Through Hole
