PT6122G
RoHS
RoHS compliant
RoHS compliantPackage 12-SIP Module
Category Power Supplies - Board Mount / DC DC Converters
Description
Switching Converters, Regulators & Controllers 3.3V 1A Wide-Inp LDO Adj Step-Down ISR
PDF
/
Inventory: 6972
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mount Through Hole
Mounting Type Through Hole, Right Angle
Package / Case 12-SIP Module
Technical
Operating Temperature -40°C~85°C
Packaging Tray
Series PT6120
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 12
ECCN Code EAR99
Type Non-Isolated PoL Module
Applications ITE (Commercial)
Additional Feature INPUT VOLTAGE CAN BE UPTO 38V WHEN THE INHIBIT FUNCTION IS NOT USED
Max Power Dissipation 3.3W
Terminal Position SINGLE
Peak Reflow Temperature (Cel) NOT SPECIFIED
Number of Functions 1
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Base Part Number PT6122
Pin Count 12
Number of Outputs 1
Qualification Status Not Qualified
Efficiency 84%
Voltage - Input (Max) 26V
Output Voltage 3.3V
Max Output Current 1A
Voltage - Input (Min) 7V
Input Voltage-Nom 9V
Switcher Configuration SINGLE
Switching Frequency-Max 600kHz
Dimensions
Height 17mm
Length 59.9mm
Width 9.65mm
Compliance
RoHS Status ROHS3 Compliant
Lead Free Lead Free
