PT6121G
RoHS
/
Package 12-SIP Module
Category Power Supplies - Board Mount / DC DC Converters
Description
REGULATOR 5.0V 1A HORZ HZ HT
PDF
/
Inventory: 5013
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mount Through Hole
Mounting Type Through Hole, Right Angle
Package / Case 12-SIP Module
Technical
Operating Temperature -40°C~85°C
Packaging Tray
Series PT6120
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 12
ECCN Code EAR99
Type Non-Isolated PoL Module
Applications ITE (Commercial)
Max Power Dissipation 5W
Terminal Position DUAL
Terminal Form GULL WING
Number of Functions 1
Base Part Number PT6121
Pin Count 12
Number of Outputs 1
Qualification Status Not Qualified
Efficiency 89%
Voltage - Input (Max) 38V
Output Voltage 5V
Max Output Current 1A
Voltage - Input (Min) 7V
Input Voltage-Nom 9V
Switcher Configuration BUCK
Switching Frequency-Max 600kHz
Dimensions
Height 17mm
Length 59.9mm
Width 9.65mm
Compliance
RoHS Status Non-RoHS Compliant
Lead Free Contains Lead
