RoHS
/
Package 12-SIP SMD Module
Category Power Supplies - Board Mount / DC DC Converters
Description REGULATOR 5.0V 1A HSMD HZ HT
PDF
/
Inventory: 7914
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

Lead Free Contains Lead
RoHS Status Non-RoHS Compliant

Dimensions

Width 9.65mm
Length 59.9mm
Height 17mm

Technical

Switching Frequency-Max 600kHz
Switcher Configuration BUCK
Input Voltage-Nom 9V
Voltage - Input (Min) 7V
Max Output Current 1A
Output Voltage 5V
Voltage - Input (Max) 38V
Efficiency 89%
Qualification Status Not Qualified
Number of Outputs 1
Pin Count 12
Base Part Number PT6121
Number of Functions 1
Terminal Form THROUGH-HOLE
Terminal Position DUAL
Max Power Dissipation 5W
Applications ITE (Commercial)
Type Non-Isolated PoL Module
ECCN Code EAR99
Number of Terminations 12
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Series PT6120
Packaging Tray
Operating Temperature -40°C~85°C

Physical

Package / Case 12-SIP SMD Module
Mounting Type Surface Mount
Mount Surface Mount
