PT6103B
RoHS
RoHS compliant
RoHS compliantPackage 12-SIP SMD Module
Category Power Supplies - Board Mount / DC DC Converters
Description
REGULATOR 12.0V 1A HSMD HZ HT
PDF
/
Inventory: 989
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Dimensions
Width 9.65mm
Length 59.9mm
Height 17mm
Technical
Switching Frequency-Max 600kHz
Switcher Configuration BUCK
Input Voltage-Nom 24V
Voltage - Input (Min) 16V
Max Output Current 1A
Output Voltage 12V
Voltage - Input (Max) 38V
Efficiency 91%
Qualification Status Not Qualified
Number of Outputs 1
Base Part Number PT6103
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Number of Functions 1
Peak Reflow Temperature (Cel) 215
Terminal Form FLAT
Terminal Position SINGLE
Technology HYBRID
Max Power Dissipation 12W
Applications ITE (Commercial)
Type Non-Isolated PoL Module
ECCN Code EAR99
Number of Terminations 12
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Series PT6100
Packaging Tray
Operating Temperature -40°C~85°C
Physical
Package / Case 12-SIP SMD Module
Mounting Type Surface Mount
Mount Surface Mount
