PT5827N image
Favorite
PT5827N image
Favorite
RoHS
RoHS RoHS compliant
Package 18-SIP Module
Category Power Supplies - Board Mount / DC DC Converters
Description Non-Isolated DC/DC Converters 5V 16A 12-V Input Adj Step-Down ISR
PDF
/
Buying Options
Total Price: USD $23.1
Unit Price: USD $23.1
≥1 USD $23.1
Inventory: 128
Minimum: 1
-
+

Technical Details

Compliance

Lead Free Contains Lead
RoHS Status ROHS3 Compliant
Radiation Hardening No

Dimensions

Width 7.87mm
Length 50.55mm

Technical

Isolation Non-Isolated
Switching Frequency-Max 400kHz
Switcher Configuration BUCK
Control Mode VOLTAGE-MODE
Output Current 16A
Input Voltage-Nom 12V
Voltage - Input (Min) 10.8V
Max Output Current 16A
Output Voltage 5V
Voltage - Input (Max) 13.2V
Efficiency 93%
Number of Outputs 1
Pin Count 18
Base Part Number PT5827
Depth 7.87mm
Number of Functions 1
Terminal Position SINGLE
Technology HYBRID
Max Power Dissipation 80W
Subcategory Switching Regulator or Controllers
Applications ITE (Commercial)
Type Non-Isolated PoL Module
ECCN Code EAR99
Number of Terminations 18
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Series Excalibur? PT5820
Packaging Tray
Operating Temperature -40°C~85°C

Physical

Number of Pins 18
Package / Case 18-SIP Module
Mounting Type Through Hole
Mount Through Hole
