RoHS
/
Package 18-SIP Module
Category Power Supplies - Board Mount / DC DC Converters
Description DC DC CONVERTER 2.5V 20A
PDF
/
Inventory: 7912
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Physical

Mount Through Hole
Mounting Type Through Hole
Package / Case 18-SIP Module

Technical

Operating Temperature -40°C~85°C
Packaging Tray
Series Excalibur? PT5810
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 18
ECCN Code EAR99
Type Non-Isolated PoL Module
Applications ITE (Commercial)
Subcategory Switching Regulator or Controllers
Max Power Dissipation 50W
Technology HYBRID
Terminal Position SINGLE
Number of Functions 1
Base Part Number PT5812
Pin Count 18
Number of Outputs 1
Qualification Status Not Qualified
Efficiency 93%
Voltage - Input (Max) 3.65V
Max Output Current 20A
Voltage - Output 1 2.5V
Voltage - Input (Min) 2.95V
Input Voltage-Nom 3.3V
Control Mode VOLTAGE-MODE
Switcher Configuration BUCK
Switching Frequency-Max 350kHz

Dimensions

Height 25.9mm
Length 50.8mm
Width 7.87mm

Compliance

RoHS Status Non-RoHS Compliant
Lead Free Contains Lead
