PT5804N
RoHS
RoHS compliant
RoHS compliantPackage 18-SIP Module
Category Power Supplies - Board Mount / DC DC Converters
Description
Module DC-DC 1-OUT 1.5V 18A 18-Pin SIP Module
PDF
/
Inventory: 10050
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Contains Lead
RoHS Status ROHS3 Compliant
Dimensions
Width 7.87mm
Length 50.55mm
Technical
Isolation Non-Isolated
Switching Frequency-Max 350kHz
Switcher Configuration BUCK
Control Mode VOLTAGE-MODE
Output Current 18A
Input Voltage-Nom 5V
Voltage - Input (Min) 4.5V
Max Output Current 18A
Output Voltage 1.5V
Voltage - Input (Max) 5.5V
Efficiency 88%
Qualification Status Not Qualified
Number of Outputs 1
Pin Count 18
Base Part Number PT5804
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Depth 7.87mm
Number of Functions 1
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Position SINGLE
Technology HYBRID
Max Power Dissipation 27W
Subcategory Switching Regulator or Controllers
Applications ITE (Commercial)
Type Non-Isolated PoL Module
ECCN Code EAR99
Number of Terminations 18
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code no
Series Excalibur? PT5800
Packaging Tray
Operating Temperature -40°C~85°C
Physical
Number of Pins 18
Package / Case 18-SIP Module
Mounting Type Through Hole
Mount Through Hole
