PT5801N
RoHS
RoHS compliant
RoHS compliantPackage 18-SIP Module
Category Power Supplies - Board Mount / DC DC Converters
Description
Module DC-DC 5VIN 1-OUT 3.3V 18A 18-Pin SIP Module
PDF
/
Buying Options
Total Price: USD $30.04
Unit Price: USD $30.0432
≥1 USD $30.0432
Inventory: 67
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Dimensions
Length 50.55mm
Technical
Isolation Non-Isolated
Switching Frequency-Max 350kHz
Switcher Configuration BUCK
Control Mode VOLTAGE-MODE
Output Current 18A
Input Voltage-Nom 5V
Voltage - Input (Min) 4.5V
Max Output Current 18A
Output Voltage 3.3V
Voltage - Input (Max) 5.5V
Efficiency 94%
Qualification Status Not Qualified
Number of Outputs 1
Pin Count 18
Base Part Number PT5801
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Depth 7.87mm
Number of Functions 1
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Position SINGLE
Technology HYBRID
Max Power Dissipation 59.4W
Subcategory Switching Regulator or Controllers
Applications ITE (Commercial)
Type Non-Isolated PoL Module
ECCN Code EAR99
Number of Terminations 18
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Series Excalibur? PT5800
Packaging Tray
Operating Temperature -40°C~85°C
Physical
Number of Pins 18
Package / Case 18-SIP Module
Mounting Type Through Hole
Mount Through Hole
