PT5545C
RoHS
/
Package 3-SMD Module
Category Power Supplies - Board Mount / DC DC Converters
Description
REG 9V 1.5A 4.5/8VIN SMD
PDF
/
Buying Options
Total Price: USD $29.95
Unit Price: USD $29.953814
≥1 USD $29.953814
≥210 USD $11.952642
≥510 USD $11.55352
≥990 USD $11.355272
Inventory: 8955
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Contains Lead
RoHS Status Non-RoHS Compliant
Technical
Switching Frequency-Max 400kHz
Control Technique PULSE WIDTH MODULATION
Control Mode VOLTAGE-MODE
Topology Boost
Voltage - Input (Min) 4.5V
Voltage - Output 1 9V
Max Output Current 1.5A
Voltage - Input (Max) 8V
Efficiency 86%
Qualification Status Not Qualified
Number of Outputs 1
JESD-30 Code R-XSMA-G3
Base Part Number PT5545
Terminal Pitch 2.54mm
Number of Functions 1
Terminal Form GULL WING
Terminal Position SINGLE
Technology HYBRID
Max Power Dissipation 13.5W
Subcategory Switching Regulator or Controllers
Applications ITE (Commercial)
Type Non-Isolated PoL Module
ECCN Code EAR99
Number of Terminations 3
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Feature UVLO
Series Excalibur? PT5540 (12W)
Packaging Tray
Operating Temperature -40°C~85°C
Physical
Package / Case 3-SMD Module
Mounting Type Surface Mount
Mount Surface Mount
Alternative Model
