PT5506C image
Favorite
PT5506C image
Favorite
RoHS
RoHS RoHS compliant
Package 5-SMD Module
Category Power Supplies - Board Mount / DC DC Converters
Description Module DC-DC 3.3VIN 1-OUT 1.2V 3A 5-Pin SIP Module
PDF
/
Inventory: 8758
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Physical

Mount Surface Mount
Mounting Type Surface Mount
Package / Case 5-SMD Module
Number of Pins 5

Technical

Operating Temperature -40°C~85°C
Packaging Tray
Series Excalibur? PT5500
Pbfree Code yes
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 5
ECCN Code EAR99
Type Non-Isolated PoL Module
Applications ITE (Commercial)
Subcategory Switching Regulator or Controllers
Max Power Dissipation 3.6W
Technology HYBRID
Terminal Position SINGLE
Terminal Form GULL WING
Number of Functions 1
Depth 22.86mm
Base Part Number PT5506
Pin Count 5
Number of Outputs 1
Efficiency 79%
Voltage - Input (Max) 5.5V
Output Voltage 1.2V
Max Output Current 3A
Voltage - Input (Min) 3.1V
Input Voltage-Nom 5V
Output Current 3A
Control Mode VOLTAGE-MODE
Switcher Configuration BUCK
Isolation Non-Isolated

Dimensions

Length 28.19mm
Width 22.9mm

Compliance

Radiation Hardening No
RoHS Status ROHS3 Compliant
Lead Free Lead Free
