PT5504N
RoHS
RoHS compliant
RoHS compliantPackage 5-SIP Module
Category Power Supplies - Board Mount / DC DC Converters
Description
Non-Isolated DC/DC Converters ADJ STEP-DOWN ISR
PDF
/
Buying Options
Total Price: USD $80.85
Unit Price: USD $80.851844
≥1 USD $80.851844
≥10 USD $76.275324
≥100 USD $71.957852
≥500 USD $67.884769
≥1000 USD $64.04223
Inventory: 1456
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Technical
Switching Frequency-Max 350kHz
Switcher Configuration BUCK
Control Mode VOLTAGE-MODE
Current - Output (Max) 3A
Input Voltage-Nom 5V
Voltage - Input (Min) 3.1V
Voltage - Output 1 1.8V
Voltage - Input (Max) 5.5V
Efficiency 83%
Qualification Status Not Qualified
Number of Outputs 1
JESD-30 Code R-XSMA-T5
Pin Count 5
Base Part Number PT5504
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Number of Functions 1
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Position SINGLE
Technology HYBRID
Subcategory Switching Regulator or Controllers
Applications ITE (Commercial)
Type Non-Isolated PoL Module
ECCN Code EAR99
Number of Terminations 5
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code no
Size / Dimension 0.90Lx0.48W x 0.95 H 22.9mmx12.2mmx24.1mm
Series Excalibur? PT5500
Packaging Tray
Operating Temperature -40°C~85°C
Physical
Surface Mount NO
Package / Case 5-SIP Module
Mounting Type Through Hole
