PT5407A
RoHS
RoHS compliant
RoHS compliantPackage 5-SIP Module
Category Power Supplies - Board Mount / DC DC Converters
Description
DC DC CONVERTER 1V 5.5A
PDF
/
Inventory: 7030
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Technical
Switching Frequency-Max 700kHz
Switcher Configuration BUCK
Control Mode VOLTAGE-MODE
Current - Output (Max) 5.5A
Input Voltage-Nom 3.3V
Voltage - Input (Min) 3.1V
Voltage - Output 1 1V
Voltage - Input (Max) 5.5V
Efficiency 80%
Qualification Status Not Qualified
Number of Outputs 1
JESD-30 Code R-MSMA-T5
Pin Count 5
Base Part Number PT5407
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Terminal Pitch 2.54mm
Number of Functions 1
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Position SINGLE
Technology HYBRID
Subcategory Switching Regulator or Controllers
Applications ITE (Commercial)
Type Non-Isolated PoL Module
ECCN Code EAR99
Number of Terminations 5
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code yes
Feature UVLO
Size / Dimension 1.11Lx0.90W x 0.31 H 28.2mmx22.9mmx7.9mm
Series Excalibur? PT5400
Packaging Tray
Operating Temperature -40°C~85°C
Physical
Surface Mount NO
Package / Case 5-SIP Module
Mounting Type Through Hole, Right Angle
