PT5406C
RoHS
RoHS compliant
RoHS compliantPackage 5-SMD Module
Category Power Supplies - Board Mount / DC DC Converters
Description
Module DC-DC 3.3V/5VIN 1-OUT 1.2V 6A 5-Pin SIP Module
PDF
/
Inventory: 2379
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Height 7.874mm
Technical
Isolation Non-Isolated
Switching Frequency-Max 700kHz
Switcher Configuration BUCK
Nominal Input Voltage 5V
Current - Output 1 6A
Control Mode VOLTAGE-MODE
Output Power 7.2W
Output Current 6A
Input Voltage-Nom 3.3V
Voltage - Input (Min) 3.1V
Max Output Current 5.5A
Output Voltage 1.2V
Voltage - Input (Max) 5.5V
Efficiency 82%
Number of Outputs 1
Pin Count 5
Base Part Number PT5406
Depth 22.86mm
Number of Functions 1
Terminal Form GULL WING
Terminal Position SINGLE
Technology HYBRID
Max Power Dissipation 6.6W
Subcategory Switching Regulator or Controllers
Applications ITE (Commercial)
Type Non-Isolated PoL Module
ECCN Code EAR99
Number of Terminations 5
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Obsolete
Pbfree Code yes
Size / Dimension 1.11Lx0.90W x 0.31 H 28.2mmx22.9mmx7.9mm
Series Excalibur? PT5400
Packaging Tray
Operating Temperature -40°C~85°C
Physical
Number of Pins 5
Package / Case 5-SMD Module
Mounting Type Surface Mount
Mount Surface Mount
