PT5405C
RoHS
RoHS compliant
RoHS compliantPackage 5-SMD Module
Category Power Supplies - Board Mount / DC DC Converters
Description
Module DC-DC 3.3V/5VIN 1-OUT 1.5V 6A 5-Pin SIP Module
PDF
/
Buying Options
Total Price: USD $411.43
Unit Price: USD $411.430846
≥1 USD $411.430846
≥10 USD $397.902175
≥25 USD $395.136225
≥50 USD $392.389494
≥100 USD $384.318797
≥500 USD $356.841967
Inventory: 1501
Minimum: 1
-
+
Technical Details
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 5-SMD Module
Number of Pins 5
Technical
Operating Temperature -40°C~85°C
Packaging Tray
Series Excalibur? PT5400
Size / Dimension 1.11Lx0.90W x 0.31 H 28.2mmx22.9mmx7.9mm
Pbfree Code yes
Part Status Obsolete
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Number of Terminations 5
ECCN Code EAR99
Type Non-Isolated PoL Module
Applications ITE (Commercial)
Subcategory Switching Regulator or Controllers
Max Power Dissipation 8.3W
Technology HYBRID
Terminal Position SINGLE
Terminal Form GULL WING
Number of Functions 1
Depth 22.86mm
Current Rating 6A
Base Part Number PT5405
Pin Count 5
Number of Outputs 1
Efficiency 85%
Voltage - Input (Max) 5.5V
Output Voltage 1.8V
Max Output Current 5.5A
Voltage - Output 1 1.5V
Voltage - Input (Min) 3.1V
Input Voltage-Nom 3.3V
Output Current 250mA
Output Power 9W
Control Mode VOLTAGE-MODE
Current - Output 1 6A
Nominal Input Voltage 5V
Switcher Configuration BUCK
Switching Frequency-Max 700kHz
Isolation Non-Isolated
Dimensions
Height 7.874mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
Lead Free Lead Free
