PT5112C
RoHS
RoHS compliant
RoHS compliantPackage 3-SMD Module
Category Power Supplies - Board Mount / DC DC Converters
Description
DC DC CONVERTER 8V 8W
PDF
/
Buying Options
Total Price: USD $12
Unit Price: USD $12.002295
≥1 USD $12.002295
≥10 USD $11.32292
≥100 USD $10.681999
≥500 USD $10.077363
≥1000 USD $9.506944
Inventory: 1419
Minimum: 1
-
+
Technical Details
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 3-SMD Module
Number of Pins 3
Technical
Operating Temperature -40°C~85°C
Packaging Tray
Series PT5100
Size / Dimension 1.00Lx1.02W x 0.38 H 25.4mmx25.9mmx9.7mm
Feature OCP, OTP
Pbfree Code yes
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 3
ECCN Code EAR99
Type Linear Regulator Replacement
Applications ITE (Commercial)
Power (Watts) 8W
Subcategory Switching Regulator or Controllers
Max Power Dissipation 8W
Technology HYBRID
Terminal Position SINGLE
Terminal Form GULL WING
Peak Reflow Temperature (Cel) NOT SPECIFIED
Number of Functions 1
Terminal Pitch 2.54mm
Depth 25.9mm
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Base Part Number PT5112
Number of Outputs 1
Qualification Status Not Qualified
Efficiency 91%
Voltage - Input (Max) 38V
Output Voltage 8V
Max Output Current 1A
Voltage - Input (Min) 12V
Input Voltage-Nom 12V
Output Current 1A
Control Mode VOLTAGE-MODE
Switcher Configuration BUCK
Switching Frequency-Max 800kHz
Isolation Non-Isolated
Dimensions
Height 9.652mm
Compliance
RoHS Status ROHS3 Compliant
Lead Free Lead Free
