PT5111CT
RoHS
RoHS compliant
RoHS compliantPackage 3-SMD Module
Category Power Supplies - Board Mount / DC DC Converters
Description
DC DC CONVERTER 10V 10W
PDF
/
Buying Options
Total Price: USD $9.95
Unit Price: USD $9.9541
≥1 USD $9.9541
≥10 USD $8.1681
≥100 USD $7.91255
≥500 USD $7.657
≥1000 USD $7.4024
Inventory: 1381
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Dimensions
Height 9.652mm
Technical
Switching Frequency-Max 800kHz
Switcher Configuration BUCK
Voltage - Input (Min) 14V
Max Output Current 1A
Output Voltage 10V
Voltage - Input (Max) 38V
Efficiency 92%
Qualification Status Not Qualified
Number of Outputs 1
JESD-30 Code R-PSMA-G3
Pin Count 3
Base Part Number PT5111
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Number of Functions 1
Peak Reflow Temperature (Cel) 215
Terminal Form GULL WING
Terminal Position SINGLE
Max Power Dissipation 10W
Power (Watts) 10W
Applications ITE (Commercial)
Type Linear Regulator Replacement
ECCN Code EAR99
Number of Terminations 3
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Feature OCP, OTP
Size / Dimension 1.02Lx1.00W x 0.38 H 25.9mmx25.4mmx9.7mm
Series PT5100
Packaging Tape & Reel (TR)
Operating Temperature -40°C~85°C
Physical
Package / Case 3-SMD Module
Mounting Type Surface Mount
Mount Surface Mount
