PT5103J
RoHS
RoHS compliant
RoHS compliantPackage 3-SMD Module
Category Power Supplies - Board Mount / DC DC Converters
Description
REGULATOR 3.3V 1A SMD VT-HT
PDF
/
Buying Options
Total Price: USD $52.59
Unit Price: USD $52.594956
≥1 USD $52.594956
≥10 USD $49.61788
≥100 USD $46.809323
≥500 USD $44.159739
≥1000 USD $41.66013
Inventory: 1532
Minimum: 1
-
+
Technical Details
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 3-SMD Module
Technical
Operating Temperature -40°C~85°C
Packaging Tray
Series PT5100
Size / Dimension 1.39Lx1.00W x 0.38 H 35.3mmx25.4mmx9.7mm
Feature OCP, OTP
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 3
ECCN Code EAR99
Type Linear Regulator Replacement
Applications ITE (Commercial)
Power (Watts) 3W
Subcategory Switching Regulator or Controllers
Max Power Dissipation 3.3W
Technology HYBRID
Terminal Position SINGLE
Terminal Form GULL WING
Peak Reflow Temperature (Cel) NOT SPECIFIED
Number of Functions 1
Terminal Pitch 2.54mm
Reach Compliance Code unknown
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Base Part Number PT5103
JESD-30 Code R-XSMA-G3
Number of Outputs 1
Qualification Status Not Qualified
Efficiency 82%
Voltage - Input (Max) 26V
Output Voltage 3.3V
Max Output Current 1A
Voltage - Input (Min) 9V
Input Voltage-Nom 9V
Control Mode VOLTAGE-MODE
Switcher Configuration BUCK
Switching Frequency-Max 875kHz
Dimensions
Height 9.652mm
Compliance
RoHS Status ROHS3 Compliant
Lead Free Lead Free
