PT5061B
RoHS
RoHS compliant
RoHS compliantPackage 12-SIP SMD Module
Category Power Supplies - Board Mount / DC DC Converters
Description
REGLTR +-12V 9W 12PINXL HSMD HZ
PDF
/
Inventory: 7073
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Technical
Switching Frequency-Max 650kHz
Switcher Configuration BOOST
Control Mode VOLTAGE-MODE
Voltage - Output 2 -12V
Current - Output (Max) 500mA 250mA
Input Voltage-Nom 5V
Voltage - Input (Min) 4.75V
Voltage - Output 1 12V
Max Output Current 250mA
Voltage - Input (Max) 11V
Efficiency 85%
Qualification Status Not Qualified
Number of Outputs 2
Pin Count 12
Base Part Number PT5061
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Number of Functions 1
Peak Reflow Temperature (Cel) 215
Terminal Form GULL WING
Terminal Position SINGLE
Technology HYBRID
Max Power Dissipation 9W
Subcategory Switching Regulator or Controllers
Applications ITE (Commercial)
Type Non-Isolated PoL Module
ECCN Code EAR99
Number of Terminations 12
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Series PT5060 (9W)
Packaging Tray
Operating Temperature 0°C~85°C
Physical
Package / Case 12-SIP SMD Module
Mounting Type Surface Mount
Mount Surface Mount
