PT5049N
RoHS
RoHS compliant
RoHS compliantPackage 3-SIP Module
Category Power Supplies - Board Mount / DC DC Converters
Description
REG SW 20V .5A STEP-UP VERT
PDF
/
Buying Options
Total Price: USD $78.38
Unit Price: USD $78.376787
≥1 USD $78.376787
≥10 USD $73.940367
≥100 USD $69.755061
≥500 USD $65.806664
≥1000 USD $62.081756
Inventory: 957
Minimum: 1
-
+
Technical Details
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case 3-SIP Module
Number of Pins 3
Technical
Operating Temperature -20°C~85°C
Packaging Tray
Series PT5040
Pbfree Code yes
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 3
ECCN Code EAR99
Type Non-Isolated PoL Module
Applications ITE (Commercial)
Subcategory Switching Regulator or Controllers
Max Power Dissipation 10W
Technology HYBRID
Terminal Position SINGLE
Peak Reflow Temperature (Cel) NOT SPECIFIED
Number of Functions 1
Depth 25.4mm
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Base Part Number PT5049
Pin Count 3
Number of Outputs 1
Qualification Status Not Qualified
Efficiency 85%
Voltage - Input (Max) 14V
Output Voltage 2V
Max Output Current 500mA
Voltage - Output 1 20V
Voltage - Input (Min) 4.75V
Input Voltage-Nom 5V
Output Current 500mA
Topology Boost
Control Mode VOLTAGE-MODE
Switching Frequency-Max 950kHz
Dimensions
Length 25.9mm
Width 9.65mm
Compliance
RoHS Status ROHS3 Compliant
Lead Free Lead Free
