PT5049M
RoHS
RoHS compliant
RoHS compliantPackage 3-SIP Module
Category Power Supplies - Board Mount / DC DC Converters
Description
REGULTR 20V 0.5A 3 PIN CU HS TH
PDF
/
Inventory: 8804
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Dimensions
Width 9.65mm
Length 25.4mm
Height 25.9mm
Technical
Switching Frequency-Max 950kHz
Control Mode VOLTAGE-MODE
Topology Boost
Input Voltage-Nom 5V
Voltage - Input (Min) 4.75V
Max Output Current 500mA
Output Voltage 20V
Voltage - Input (Max) 14V
Efficiency 85%
Qualification Status Not Qualified
Number of Outputs 1
Pin Count 3
Base Part Number PT5049
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Terminal Pitch 2.54mm
Number of Functions 1
Peak Reflow Temperature (Cel) 215
Terminal Position SINGLE
Technology HYBRID
Max Power Dissipation 10W
Subcategory Switching Regulator or Controllers
Applications ITE (Commercial)
Type Non-Isolated PoL Module
ECCN Code EAR99
Number of Terminations 3
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Series PT5040
Packaging Tray
Operating Temperature -20°C~85°C
Physical
Number of Pins 3
Package / Case 3-SIP Module
Mounting Type Through Hole, Right Angle
Mount Through Hole
