PT5046A
RoHS
RoHS compliant
RoHS compliantPackage 3-SIP Module
Category Power Supplies - Board Mount / DC DC Converters
Description
REG SW 10V 1.2A STEP-UP HORZ
PDF
/
Inventory: 6364
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mount Through Hole
Mounting Type Through Hole, Right Angle
Package / Case 3-SIP Module
Technical
Operating Temperature -20°C~85°C
Packaging Tray
Series PT5040
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Type Non-Isolated PoL Module
Max Operating Temperature 85°C
Min Operating Temperature -20°C
Applications ITE (Commercial)
Max Power Dissipation 12W
Current Rating 1.2A
Base Part Number PT5046
Number of Outputs 1
Efficiency 85%
Voltage - Input (Max) 9V
Output Voltage 10V
Max Output Current 1.2A
Voltage - Output 1 10V
Voltage - Input (Min) 4.75V
Current - Output (Max) 1.2A
Output Current 1.2A
Topology Boost
Min Input Voltage 4.75V
Max Input Voltage 9V
Dimensions
Height 25.9mm
Length 25.4mm
Width 9.65mm
Compliance
RoHS Status ROHS3 Compliant
Lead Free Contains Lead
