PT5045S image
Favorite
PT5045S image
Favorite
RoHS
RoHS RoHS compliant
Package 3-SIP Module
Category Power Supplies - Board Mount / DC DC Converters
Description REGULATOR 9V 1.25A 3PSIP VT VTHT
PDF
/
Inventory: 1715
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

Lead Free Lead Free
RoHS Status ROHS3 Compliant

Dimensions

Width 9.65mm
Length 25.4mm
Height 35.3mm

Technical

Switching Frequency-Max 800kHz
Topology Boost
Input Voltage-Nom 5V
Voltage - Input (Min) 4.75V
Max Output Current 1.2A
Output Voltage 9V
Voltage - Input (Max) 8V
Efficiency 85%
Qualification Status Not Qualified
Number of Outputs 1
JESD-30 Code R-PSMA-T3
Base Part Number PT5045
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Number of Functions 1
Peak Reflow Temperature (Cel) 215
Terminal Position SINGLE
Max Power Dissipation 10.8W
Applications ITE (Commercial)
Type Non-Isolated PoL Module
ECCN Code EAR99
Number of Terminations 3
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Series PT5040
Packaging Tray
Operating Temperature -20°C~85°C

Physical

Package / Case 3-SIP Module
Mounting Type Through Hole
Mount Through Hole
