PT5045H
RoHS
RoHS compliant
RoHS compliantPackage 3-SIP Module
Category Power Supplies - Board Mount / DC DC Converters
Description
REGULTR 9V 1.25A 3 PIN HZ VT HT
PDF
/
Inventory: 8271
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case 3-SIP Module
Number of Pins 3
Technical
Operating Temperature -20°C~85°C
Packaging Tray
Series PT5040
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 3
ECCN Code EAR99
Type Non-Isolated PoL Module
Applications ITE (Commercial)
Max Power Dissipation 10.8W
Terminal Position SINGLE
Peak Reflow Temperature (Cel) 215
Number of Functions 1
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Base Part Number PT5045
Number of Outputs 1
Qualification Status Not Qualified
Efficiency 85%
Voltage - Input (Max) 8V
Output Voltage 9V
Max Output Current 1.2A
Voltage - Input (Min) 4.75V
Input Voltage-Nom 5V
Topology Boost
Switching Frequency-Max 800kHz
Dimensions
Height 35.3mm
Length 25.4mm
Width 9.65mm
Compliance
RoHS Status ROHS3 Compliant
Lead Free Lead Free
