PT5029C
RoHS
RoHS compliant
RoHS compliantPackage 3-SMD Module
Category Power Supplies - Board Mount / DC DC Converters
Description
REGULATOR -5.5V 1A 3PSIP HRZ SMD
PDF
/
Inventory: 4567
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Dimensions
Width 9.65mm
Length 25.4mm
Height 25.9mm
Technical
Switcher Configuration BUCK-BOOST
Current - Output 1 1A
Control Mode VOLTAGE-MODE
Input Voltage-Nom 5V
Voltage - Input (Min) 4.75V
Max Output Current 1A
Output Voltage -5.5V
Voltage - Input (Max) 7V
Efficiency 75%
Qualification Status Not Qualified
Number of Outputs 1
JESD-30 Code R-XSMA-G3
Pin Count 3
Base Part Number PT5029
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Terminal Pitch 2.54mm
Number of Functions 1
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Form GULL WING
Terminal Position SINGLE
Technology HYBRID
Max Power Dissipation 5.5W
Subcategory Switching Regulator or Controllers
Applications ITE (Commercial)
Type Non-Isolated PoL Module
ECCN Code EAR99
Number of Terminations 3
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Series PT5020
Packaging Tray
Operating Temperature -20°C~85°C
Physical
Package / Case 3-SMD Module
Mounting Type Surface Mount
Mount Surface Mount
