PT5025A
RoHS
RoHS compliant
RoHS compliantPackage 3-SIP Module
Category Power Supplies - Board Mount / DC DC Converters
Description
REGULTR -15V 0.3A 3 PIN HORZ
PDF
/
Inventory: 1370
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mount Through Hole
Mounting Type Through Hole, Right Angle
Package / Case 3-SIP Module
Number of Pins 3
Technical
Operating Temperature -20°C~85°C
Packaging Tray
Series PT5020
Pbfree Code yes
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 3
ECCN Code EAR99
Type Non-Isolated PoL Module
Applications ITE (Commercial)
Subcategory Switching Regulator or Controllers
Max Power Dissipation 4.5W
Technology HYBRID
Terminal Position SINGLE
Peak Reflow Temperature (Cel) NOT SPECIFIED
Number of Functions 1
Terminal Pitch 2.54mm
Depth 25.15mm
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Base Part Number PT5025
Pin Count 3
Number of Outputs 1
Qualification Status Not Qualified
Efficiency 75%
Voltage - Input (Max) 7V
Output Voltage -15V
Max Output Current 300mA
Voltage - Input (Min) 4.75V
Input Voltage-Nom 5V
Output Current 300mA
Control Mode VOLTAGE-MODE
Switcher Configuration BUCK-BOOST
Switching Frequency-Max 800kHz
Dimensions
Length 25.65mm
Width 9.65mm
Compliance
RoHS Status ROHS3 Compliant
Lead Free Lead Free
