PT5024S image
Favorite
PT5024S image
Favorite
RoHS
RoHS RoHS compliant
Package 3-SIP Module
Category Power Supplies - Board Mount / DC DC Converters
Description REGULTR -12V 0.5A 3PIN VERT VTHT
PDF
/
Inventory: 6072
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Physical

Mount Through Hole
Mounting Type Through Hole
Package / Case 3-SIP Module
Number of Pins 3

Technical

Operating Temperature -20°C~85°C
Packaging Tray
Series PT5020
Pbfree Code yes
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 3
ECCN Code EAR99
Type Non-Isolated PoL Module
Applications ITE (Commercial)
Max Power Dissipation 6W
Technology HYBRID
Terminal Position SINGLE
Peak Reflow Temperature (Cel) NOT SPECIFIED
Number of Functions 1
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Base Part Number PT5024
Pin Count 3
Number of Outputs 1
Qualification Status Not Qualified
Efficiency 75%
Voltage - Input (Max) 7V
Output Voltage -12V
Max Output Current 500mA
Voltage - Input (Min) 4.75V
Input Voltage-Nom 5V
Current - Output 1 500mA
Switcher Configuration BUCK-BOOST
Switching Frequency-Max 800kHz

Dimensions

Height 35.3mm
Length 25.4mm
Width 9.65mm

Compliance

RoHS Status ROHS3 Compliant
Lead Free Lead Free
