PT5023N
RoHS
RoHS compliant
RoHS compliantPackage 3-SIP Module
Category Power Supplies - Board Mount / DC DC Converters
Description
DC DC CONVERTER -9V .6A
PDF
/
Buying Options
Total Price: USD $34.16
Unit Price: USD $34.159032
≥1 USD $34.159032
≥210 USD $13.629215
≥490 USD $13.174952
≥1015 USD $12.949133
Inventory: 1210
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Width 9.65mm
Length 25.4mm
Height 25.9mm
Technical
Switching Frequency-Max 800kHz
Current - Output 1 600mA
Control Mode VOLTAGE-MODE
Topology Boost
Output Current 600mA
Input Voltage-Nom 5V
Voltage - Input (Min) 4.75V
Max Output Current 600mA
Output Voltage -9V
Voltage - Input (Max) 7V
Efficiency 75%
Number of Outputs 1
JESD-30 Code R-XSMA-T3
Pin Count 3
Base Part Number PT5023
Number of Functions 1
Terminal Position SINGLE
Technology HYBRID
Max Power Dissipation 5.4W
Subcategory Switching Regulator or Controllers
Applications ITE (Commercial)
Type Non-Isolated PoL Module
ECCN Code EAR99
Number of Terminations 3
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Series PT5020
Packaging Tray
Operating Temperature -20°C~85°C
Physical
Package / Case 3-SIP Module
Mounting Type Through Hole
Mount Through Hole
