PT5023A
RoHS
RoHS compliant
RoHS compliantPackage 3-SIP Module
Category Power Supplies - Board Mount / DC DC Converters
Description
DC DC CONVERTER -9V .6A
PDF
/
Buying Options
Total Price: USD $17.84
Unit Price: USD $17.840205
≥1 USD $17.840205
≥10 USD $16.83038
≥100 USD $15.87772
≥500 USD $14.97898
≥1000 USD $14.131113
Inventory: 1613
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Contains Lead
RoHS Status ROHS3 Compliant
Dimensions
Width 9.65mm
Length 25.65mm
Technical
Switching Frequency-Max 800kHz
Control Mode VOLTAGE-MODE
Topology Boost
Output Current 600mA
Input Voltage-Nom 5V
Voltage - Input (Min) 4.75V
Max Output Current 600mA
Output Voltage -9V
Voltage - Input (Max) 7V
Efficiency 75%
Qualification Status Not Qualified
Number of Outputs 1
Pin Count 3
Base Part Number PT5023
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Depth 25.15mm
Terminal Pitch 2.54mm
Number of Functions 1
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Position SINGLE
Technology HYBRID
Max Power Dissipation 5.4W
Subcategory Switching Regulator or Controllers
Applications ITE (Commercial)
Type Non-Isolated PoL Module
ECCN Code EAR99
Number of Terminations 3
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code no
Series PT5020
Packaging Tray
Operating Temperature -20°C~85°C
Physical
Number of Pins 3
Package / Case 3-SIP Module
Mounting Type Through Hole, Right Angle
Mount Through Hole
