PT5022C image
Favorite
PT5022C image
Favorite
RoHS
RoHS RoHS compliant
Package 3-SMD Module
Category Power Supplies - Board Mount / DC DC Converters
Description REGULATOR -5V -1A 3PSIP HRZ SMD
PDF
/
Inventory: 932
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Radiation Hardening No

Dimensions

Width 9.65mm
Length 25.65mm

Technical

Min Input Voltage (DC) 4.75V
Max Input Voltage (DC) 7V
Nominal Output Voltage -5V
Max Output Power -5W
Switcher Configuration BUCK-BOOST
Control Mode VOLTAGE-MODE
Output Power -5W
Output Current 1A
Input Voltage-Nom 5V
Max Output Current 1A
Output Voltage -5V
Efficiency 75%
Number of Outputs 1
Pin Count 3
Base Part Number PT5022
Depth 25.14mm
Terminal Pitch 2.54mm
Number of Functions 1
Peak Reflow Temperature (Cel) 215
Terminal Form GULL WING
Terminal Position SINGLE
Technology HYBRID
Max Power Dissipation 5W
Subcategory Switching Regulator or Controllers
HTS Code 8504.40.85.00
Applications ITE (Commercial)
Type Non-Isolated PoL Module
ECCN Code EAR99
Number of Terminations 3
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code yes
Series PT5020
Packaging Tray
Operating Temperature -20°C~85°C

Physical

Weight 4.5g
Number of Pins 3
Package / Case 3-SMD Module
Mounting Type Surface Mount
Mount Surface Mount
