PT4852C
RoHS
RoHS compliant
RoHS compliantPackage 26-SMD Module
Category Power Supplies - Board Mount / DC DC Converters
Description
DC DC CNVRTR 3.3V 1.8V 1.5V 49W
PDF
/
Inventory: 7092
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 26-SMD Module
Number of Pins 26
Technical
Operating Temperature -40°C~85°C
Packaging Tray
Series Excalibur? PT4850
Size / Dimension 3.61Lx1.62W x 0.50 H 91.7mmx41.1mmx12.7mm
Feature Remote On/Off, OCP, OTP, OVP, UVLO
Part Status Obsolete
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Number of Terminations 25
Voltage - Output 3 1.5V
Voltage - Output 2 1.8V
Current - Output (Max) 15A 10A 10A
Trim/Adjustable Output YES
Input Voltage-Nom 48V
Voltage - Input (Min) 36V
Max Output Current 10A
Output Voltage 3.3V
Voltage - Input (Max) 75V
Voltage - Isolation 1.5kV
Efficiency 85%
Qualification Status Not Qualified
Number of Outputs 3
JESD-30 Code R-MSMA-G25
Base Part Number PT4852
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Reach Compliance Code not_compliant
Depth 37.85mm
Terminal Pitch 2.54mm
Number of Functions 1
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Form GULL WING
Terminal Position SINGLE
Technology HYBRID
Max Power Dissipation 49.5W
Subcategory Other Analog ICs
Power (Watts) 49W
Applications ITE (Commercial)
Type Isolated Module
ECCN Code EAR99
Compliance
Lead Free Contains Lead
RoHS Status ROHS3 Compliant
Dimensions
Height 12.7mm
