PT4832N
RoHS
RoHS compliant
RoHS compliantPackage 21-SIP Module
Category Power Supplies - Board Mount / DC DC Converters
Description
DC DC CONVERTER 5V 3.3V 2.5V 35W
PDF
/
Inventory: 1653
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case 21-SIP Module
Number of Pins 21
Technical
Operating Temperature -40°C~85°C
Packaging Tray
Series Excalibur? PT4820 (35W)
Feature UVLO
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 18
ECCN Code EAR99
Type Isolated Module
Applications ITE (Commercial)
Subcategory Other Analog ICs
Max Power Dissipation 35W
Technology HYBRID
Terminal Position SINGLE
Peak Reflow Temperature (Cel) NOT SPECIFIED
Number of Functions 1
Depth 11.75mm
Reach Compliance Code not_compliant
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Base Part Number PT4832
JESD-30 Code R-MSMA-T18
Number of Outputs 3
Qualification Status Not Qualified
Efficiency 86.7%
Voltage - Isolation 1.5kV
Voltage - Input (Max) 75V
Output Voltage 5V
Max Output Current 5.5A
Voltage - Input (Min) 36V
Input Voltage-Nom 48V
Trim/Adjustable Output YES
Current - Output (Max) 5A 5.5A 5.5A
Output Power 35W
Voltage - Output 2 3.3V
Voltage - Output 3 2.5V
Dimensions
Length 65.28mm
Width 12mm
Compliance
RoHS Status ROHS3 Compliant
Lead Free Contains Lead
