PT4829A
RoHS
RoHS compliant
RoHS compliantPackage 21-SIP Module
Category Power Supplies - Board Mount / DC DC Converters
Description
DC DC CONVERTER 5V 1.8V 1.5V 35W
PDF
/
Inventory: 1686
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mount Through Hole
Mounting Type Through Hole, Right Angle
Package / Case 21-SIP Module
Number of Pins 21
Technical
Operating Temperature -40°C~85°C
Packaging Tray
Series Excalibur? PT4820 (35W)
Feature UVLO
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 18
ECCN Code EAR99
Type Isolated Module
Applications ITE (Commercial)
Subcategory Other Analog ICs
Max Power Dissipation 35W
Technology HYBRID
Terminal Position SINGLE
Number of Functions 1
Terminal Pitch 2.54mm
Base Part Number PT4829
JESD-30 Code R-MSMA-T18
Number of Outputs 3
Efficiency 86.2%
Voltage - Isolation 1.5kV
Voltage - Input (Max) 75V
Output Voltage 5V
Max Output Current 5.5A
Voltage - Input (Min) 36V
Input Voltage-Nom 48V
Trim/Adjustable Output YES
Current - Output (Max) 5A 5.5A 5.5A
Output Power 35W
Voltage - Output 2 1.8V
Voltage - Output 3 1.5V
Dimensions
Length 65.28mm
Width 37.1mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
Lead Free Contains Lead
