PT4711C
RoHS
RoHS compliant
RoHS compliantPackage 21-SMD Module
Category Power Supplies - Board Mount / DC DC Converters
Description
CONV DC/DC 15V 48VIN 45W SMD
PDF
/
Buying Options
Total Price: USD $73.35
Unit Price: USD $73.346074
≥1 USD $73.346074
≥10 USD $69.194416
≥100 USD $65.277751
≥500 USD $61.582784
≥1000 USD $58.096967
Inventory: 1403
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Contains Lead
RoHS Status ROHS3 Compliant
Dimensions
Height 11.938mm
Technical
Voltage - Output 2 -15V
Current - Output (Max) 1.5A 1.5A
Trim/Adjustable Output YES
Input Voltage-Nom 48V
Voltage - Input (Min) 36V
Voltage - Output 1 15V
Max Output Current 1.5A
Output Voltage 15V
Voltage - Input (Max) 75V
Voltage - Isolation 1.5kV
Efficiency 86%
Qualification Status Not Qualified
Number of Outputs 2
Pin Count 21
Base Part Number PT4711
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Reach Compliance Code not_compliant
Number of Functions 1
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Form GULL WING
Terminal Position SINGLE
Technology HYBRID
Max Power Dissipation 45W
Subcategory Other Analog ICs
Applications ITE (Commercial)
Type Isolated Module
ECCN Code EAR99
Number of Terminations 21
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Obsolete
Pbfree Code no
Feature Remote On/Off, OCP, OTP, UVLO
Size / Dimension 2.58Lx1.62W x 0.47 H 65.5mmx41.1mmx12.0mm
Series Excalibur? PT4711 (45W)
Packaging Tray
Operating Temperature -40°C~85°C
Physical
Package / Case 21-SMD Module
Mounting Type Surface Mount
Mount Surface Mount
