PT4683N
RoHS
RoHS compliant
RoHS compliantPackage 26-SIP Module
Category Power Supplies - Board Mount / DC DC Converters
Description
CONV DC-DC 24VIN 3.3/1.8V VERT
PDF
/
Inventory: 5359
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case 26-SIP Module
Technical
Operating Temperature -40°C~85°C
Packaging Tray
Series Excalibur? PT4680
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 26
ECCN Code EAR99
Type Isolated Module
Applications ITE (Commercial)
Subcategory Other Analog ICs
Max Power Dissipation 49W
Technology HYBRID
Terminal Position SINGLE
Peak Reflow Temperature (Cel) NOT SPECIFIED
Number of Functions 1
Reach Compliance Code not_compliant
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Base Part Number PT4683
Pin Count 26
Number of Outputs 2
Qualification Status Not Qualified
Efficiency 87%
Voltage - Isolation 1.5kV
Voltage - Input (Max) 36V
Output Voltage 3.3V
Max Output Current 15A
Voltage - Output 1 3.3V
Voltage - Input (Min) 18V
Input Voltage-Nom 24V
Trim/Adjustable Output YES
Current - Output (Max) 15A 15A
Voltage - Output 2 1.8V
Compliance
RoHS Status ROHS3 Compliant
Lead Free Contains Lead
