PT4682C
RoHS
RoHS compliant
RoHS compliantPackage 26-SMD Module
Category Power Supplies - Board Mount / DC DC Converters
Description
DC DC CONVERTER 3.3V 2.5V 49W
PDF
/
Inventory: 5054
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 26-SMD Module
Technical
Operating Temperature -40°C~85°C
Packaging Tray
Series Excalibur? PT4680
Size / Dimension 3.61Lx1.62W x 0.50 H 91.7mmx41.1mmx12.7mm
Feature Remote On/Off, OCP, OTP, OVP, UVLO
Voltage - Output 2 2.5V
Current - Output (Max) 15A 15A
Trim/Adjustable Output YES
Input Voltage-Nom 24V
Voltage - Input (Min) 18V
Voltage - Output 1 3.3V
Max Output Current 15A
Output Voltage 3.3V
Voltage - Input (Max) 36V
Voltage - Isolation 1.5kV
Efficiency 87%
Qualification Status Not Qualified
Number of Outputs 2
Pin Count 26
Base Part Number PT4682
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Reach Compliance Code not_compliant
Number of Functions 1
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Form GULL WING
Terminal Position SINGLE
Technology HYBRID
Max Power Dissipation 49W
Subcategory Other Analog ICs
Applications ITE (Commercial)
Type Isolated Module
ECCN Code EAR99
Number of Terminations 26
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Obsolete
Compliance
Lead Free Contains Lead
RoHS Status ROHS3 Compliant
Dimensions
Height 12.7mm
