PT4585C
RoHS
RoHS compliant
RoHS compliantPackage 19-SMD Module
Category Power Supplies - Board Mount / DC DC Converters
Description
DC DC CONVERTER 1.8V 30W
PDF
/
Buying Options
Total Price: USD $39.42
Unit Price: USD $39.424
≥1 USD $39.424
Inventory: 137
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Height 12.7mm
Technical
Isolation Isolated
Nominal Input Voltage 36V
Current - Output 1 8A
Output Power 14.4W
Output Current 8A
Trim/Adjustable Output YES
Input Voltage-Nom 24V
Voltage - Input (Min) 18V
Max Output Current 8A
Output Voltage 1.8V
Voltage - Input (Max) 60V
Voltage - Isolation 1.5kV
Efficiency 70%
Number of Outputs 1
Pin Count 19
Base Part Number PT4585
Depth 25.65mm
Terminal Pitch 2.54mm
Number of Functions 1
Terminal Form GULL WING
Terminal Position SINGLE
Technology HYBRID
Max Power Dissipation 14W
Power Rating 14.4W
Subcategory Other Analog ICs
Power (Watts) 30W
Applications ITE (Commercial)
Type Isolated Module
ECCN Code EAR99
Number of Terminations 19
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Obsolete
Feature Remote On/Off, OCP, OTP, SCP, UVLO
Size / Dimension 3.00Lx1.19W x 0.50 H 76.2mmx30.2mmx12.7mm
Series Excalibur? PT4580 (30W)
Packaging Tray
Operating Temperature -40°C~85°C
Physical
Number of Pins 19
Package / Case 19-SMD Module
Mounting Type Surface Mount
Mount Surface Mount
