PT4565N
RoHS
RoHS compliant
RoHS compliantPackage 19-SIP Module
Category Power Supplies - Board Mount / DC DC Converters
Description
CONV DC-DC 2VADJ 48VIN 8A VRT
PDF
/
Inventory: 7245
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Dimensions
Height 25.908mm
Technical
Trim/Adjustable Output YES
Input Voltage-Nom 48V
Voltage - Input (Min) 36V
Max Output Current 8A
Output Voltage 2V
Voltage - Input (Max) 75V
Voltage - Isolation 1.5kV
Efficiency 69%
Qualification Status Not Qualified
Number of Outputs 1
Pin Count 19
Base Part Number PT4565
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Number of Functions 1
Peak Reflow Temperature (Cel) 215
Terminal Position SINGLE
Technology HYBRID
Max Power Dissipation 16W
Power Rating 16W
Subcategory Other Analog ICs
Additional Feature UNDERVOLTAGE LOCKOUT
Power (Watts) 30W
Applications ITE (Commercial)
Type Isolated Module
ECCN Code EAR99
Number of Terminations 19
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Size / Dimension 3.00Lx0.67W x 1.02 H 76.2mmx17.0mmx25.9mm
Series Excalibur? PT4560 (30W)
Packaging Tray
Operating Temperature -40°C~85°C
Physical
Package / Case 19-SIP Module
Mounting Type Through Hole
Mount Through Hole
