PT4523C
RoHS
RoHS compliant
RoHS compliantPackage 12-SIP SMD Module
Category Power Supplies - Board Mount / DC DC Converters
Description
Module DC-DC 48VIN 1-OUT 12V 1.6A 20W 12-Pin SIP Module
PDF
/
Buying Options
Total Price: USD $80.03
Unit Price: USD $80.026824
≥1 USD $80.026824
≥10 USD $75.497005
≥100 USD $71.223592
≥500 USD $67.192064
≥1000 USD $63.388741
Inventory: 1389
Minimum: 1
-
+
Technical Details
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 12-SIP SMD Module
Number of Pins 12
Technical
Operating Temperature -40°C~85°C
Packaging Tray
Series Excalibur? PT4520 (20W)
Feature UVLO
Pbfree Code no
Part Status Obsolete
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Number of Terminations 12
ECCN Code EAR99
Type Isolated Module
Applications ITE (Commercial)
Subcategory Other Analog ICs
Max Power Dissipation 19.2W
Technology HYBRID
Terminal Position SINGLE
Terminal Form GULL WING
Peak Reflow Temperature (Cel) NOT SPECIFIED
Number of Functions 1
Terminal Pitch 2.54mm
Depth 30.22mm
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Base Part Number PT4523
Pin Count 12
Number of Outputs 1
Qualification Status Not Qualified
Efficiency 83%
Voltage - Isolation 1.5kV
Voltage - Input (Max) 75V
Output Voltage 12V
Max Output Current 1.6A
Voltage - Output 1 12V
Voltage - Input (Min) 36V
Input Voltage-Nom 48V
Trim/Adjustable Output YES
Output Current 1.6A
Output Power 20W
Current - Output 1 1.6A
Nominal Input Voltage 48V
Isolation Isolated
Dimensions
Length 65.53mm
Width 25.9mm
Compliance
RoHS Status ROHS3 Compliant
Lead Free Contains Lead
