PT4507A
RoHS
RoHS compliant
RoHS compliantPackage 12-SIP Module
Category Power Supplies - Board Mount / DC DC Converters
Description
Module DC-DC 24VIN 1-OUT 1.8V 5A 9W 12-Pin SIP Module
PDF
/
Buying Options
Total Price: USD $51.18
Unit Price: USD $51.180168
≥1 USD $51.180168
≥10 USD $48.283174
≥100 USD $45.550167
≥500 USD $42.971853
≥1000 USD $40.539486
Inventory: 1388
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Dimensions
Width 25.9mm
Length 65.53mm
Technical
Isolation Isolated
Nominal Input Voltage 24V
Total Power Output-Max 9W
Current - Output 1 5A
Output Power 9W
Output Current 5A
Trim/Adjustable Output YES
Input Voltage-Nom 24V
Voltage - Input (Min) 18V
Max Output Current 5A
Output Voltage 1.8V
Voltage - Input (Max) 40V
Voltage - Isolation 1.5kV
Efficiency 67%
Qualification Status Not Qualified
Number of Outputs 1
Pin Count 12
Base Part Number PT4507
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Depth 30.22mm
Terminal Pitch 2.54mm
Number of Functions 1
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Position SINGLE
Technology HYBRID
Max Power Dissipation 9W
Power Rating 9W
Subcategory Other Analog ICs
Power (Watts) 20W
Applications ITE (Commercial)
Type Isolated Module
ECCN Code EAR99
Number of Terminations 12
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code yes
Feature UVLO
Series Excalibur? PT4500 (20W)
Packaging Tray
Operating Temperature -40°C~85°C
Physical
Number of Pins 12
Package / Case 12-SIP Module
Mounting Type Through Hole, Right Angle
Mount Through Hole
