PT4475C
RoHS
RoHS compliant
RoHS compliantPackage 26-SMD Module
Category Power Supplies - Board Mount / DC DC Converters
Description
CONV DC 12VADJ 24VIN 8.5A HZ SMD
PDF
/
Inventory: 8441
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Contains Lead
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Height 12.7mm
Technical
Isolation Isolated
Control Features Enable, Active Low
Output Power 100W
Output Current 8.5A
Trim/Adjustable Output YES
Input Voltage-Nom 24V
Voltage - Input (Min) 18V
Voltage - Output 1 6.5V~17.5V
Max Output Current 8.5A
Output Voltage 17.5V
Voltage - Input (Max) 36V
Voltage - Isolation 1.5kV
Efficiency 89%
Number of Outputs 1
Pin Count 26
Base Part Number PT4475
Depth 41.14mm
Terminal Pitch 2.54mm
Number of Functions 1
Terminal Form GULL WING
Terminal Position SINGLE
Technology HYBRID
Max Power Dissipation 100W
Power Rating 100W
Subcategory Other Analog ICs
Applications ITE (Commercial)
Type Isolated Module
ECCN Code EAR99
Number of Terminations 26
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Obsolete
Feature Remote On/Off, OCP, OTP, OVP, UVLO
Size / Dimension 3.61Lx1.62W x 0.50 H 91.7mmx41.1mmx12.7mm
Series Excalibur? PT4475 (100W)
Packaging Tray
Operating Temperature -40°C~100°C
Physical
Number of Pins 26
Package / Case 26-SMD Module
Mounting Type Surface Mount
Mount Surface Mount
