PT4401N
RoHS
RoHS compliant
RoHS compliantPackage 21-SIP Module
Category Power Supplies - Board Mount / DC DC Converters
Description
Module DC-DC 48VIN 1-OUT 1.3V to 3.5V 20A 75W 21-Pin SIP Module
PDF
/
Buying Options
Total Price: USD $415.55
Unit Price: USD $415.545159
≥1 USD $415.545159
≥10 USD $401.8812
≥25 USD $399.087583
≥50 USD $396.31339
≥100 USD $388.161988
≥500 USD $360.41039
Inventory: 1122
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Contains Lead
RoHS Status ROHS3 Compliant
Dimensions
Width 12mm
Length 65.53mm
Technical
Isolation Isolated
Output Power 75W
Output Current 20A
Trim/Adjustable Output YES
Input Voltage-Nom 48V
Voltage - Input (Min) 36V
Voltage - Output 1 1.3V~3.5V
Max Output Current 20A
Output Voltage 3.5V
Voltage - Input (Max) 75V
Voltage - Isolation 1.5kV
Efficiency 89%
Qualification Status Not Qualified
Number of Outputs 1
JESD-30 Code R-MSMA-T20
Base Part Number PT4401
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Reach Compliance Code not_compliant
Depth 16mm
Number of Functions 1
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Position SINGLE
Technology HYBRID
Max Power Dissipation 70W
Power Rating 75W
Subcategory Other Analog ICs
Applications ITE (Commercial)
Type Isolated Module
ECCN Code EAR99
Number of Terminations 20
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code no
Series Excalibur? PT4400 (75W)
Packaging Tray
Operating Temperature -40°C~85°C
Physical
Number of Pins 21
Package / Case 21-SIP Module
Mounting Type Through Hole
Mount Through Hole
