PT4245A
RoHS
RoHS compliant
RoHS compliantPackage 10-SIP Module
Category Power Supplies - Board Mount / DC DC Converters
Description
CONVERTER DC-DC 24VIN 3.0A HRZ
PDF
/
Inventory: 9753
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mount Through Hole
Mounting Type Through Hole, Right Angle
Package / Case 10-SIP Module
Technical
Operating Temperature -40°C~85°C
Packaging Tray
Series Excalibur? PT4240 (10W)
Size / Dimension 2.00Lx1.19W x 0.31 H 50.8mmx30.2mmx7.9mm
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 10
ECCN Code EAR99
Type Isolated Module
Applications ITE (Commercial)
Power (Watts) 10W
Subcategory Other Analog ICs
Power Rating 7.5W
Max Power Dissipation 7.5W
Technology HYBRID
Terminal Position SINGLE
Peak Reflow Temperature (Cel) 215
Number of Functions 1
Terminal Pitch 2.54mm
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Base Part Number PT4245
Pin Count 10
Number of Outputs 1
Qualification Status Not Qualified
Efficiency 77%
Voltage - Isolation 1.5kV
Voltage - Input (Max) 36V
Output Voltage 2.5V
Max Output Current 3A
Voltage - Input (Min) 18V
Input Voltage-Nom 24V
Trim/Adjustable Output YES
Dimensions
Height 7.874mm
Compliance
RoHS Status ROHS3 Compliant
Lead Free Lead Free
