PT4242C
RoHS
RoHS compliant
RoHS compliantPackage 10-SMD Module
Category Power Supplies - Board Mount / DC DC Converters
Description
Module DC-DC 24VIN 1-OUT 3.3V 3A 10W 10-Pin SIP Module
PDF
/
Buying Options
Total Price: USD $286.2
Unit Price: USD $286.20175
≥1 USD $286.20175
Inventory: 403
Minimum: 1
-
+
Technical Details
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 10-SMD Module
Number of Pins 10
Technical
Operating Temperature -40°C~85°C
Packaging Tray
Series Excalibur? PT4240 (10W)
Size / Dimension 2.00Lx1.19W x 0.31 H 50.8mmx30.2mmx7.9mm
Feature Remote On/Off, OCP, SCP, UVLO
Pbfree Code no
Part Status Obsolete
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Number of Terminations 10
ECCN Code EAR99
Type Isolated Module
Applications ITE (Commercial)
Subcategory Other Analog ICs
Power Rating 10W
Max Power Dissipation 10W
Technology HYBRID
Terminal Position SINGLE
Terminal Form GULL WING
Peak Reflow Temperature (Cel) NOT SPECIFIED
Number of Functions 1
Terminal Pitch 2.54mm
Depth 30.22mm
Reach Compliance Code not_compliant
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Base Part Number PT4242
Pin Count 10
Number of Outputs 1
Qualification Status Not Qualified
Efficiency 80%
Voltage - Isolation 1.5kV
Voltage - Input (Max) 36V
Output Voltage 3.3V
Max Output Current 3A
Voltage - Input (Min) 18V
Input Voltage-Nom 24V
Trim/Adjustable Output YES
Output Current 3A
Output Power 10W
Current - Output 1 3A
Nominal Input Voltage 24V
Isolation Isolated
Dimensions
Height 7.874mm
Compliance
RoHS Status ROHS3 Compliant
Lead Free Contains Lead
