PT4221N
RoHS
RoHS compliant
RoHS compliantPackage 10-SIP Module
Category Power Supplies - Board Mount / DC DC Converters
Description
CONVERTER DC-DC 1.8VIN 3.0A VRT
PDF
/
Inventory: 3350
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Dimensions
Height 25.908mm
Technical
Trim/Adjustable Output YES
Input Voltage-Nom 48V
Voltage - Input (Min) 36V
Max Output Current 3A
Output Voltage 1.8V
Voltage - Input (Max) 75V
Voltage - Isolation 1.5kV
Efficiency 73%
Qualification Status Not Qualified
Number of Outputs 1
Pin Count 10
Base Part Number PT4221
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Number of Functions 1
Peak Reflow Temperature (Cel) 215
Terminal Position SINGLE
Technology HYBRID
Max Power Dissipation 5.4W
Power Rating 5.4W
Subcategory Other Analog ICs
Power (Watts) 10W
Applications ITE (Commercial)
Type Isolated Module
ECCN Code EAR99
Number of Terminations 10
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Size / Dimension 2.00Lx0.48W x 1.02 H 50.8mmx12.2mmx25.9mm
Series Excalibur? PT4220 (10W)
Packaging Tray
Operating Temperature -40°C~85°C
Physical
Package / Case 10-SIP Module
Mounting Type Through Hole
Mount Through Hole
