RoHS
RoHS RoHS compliant
Package 10-SIP Module
Category Power Supplies - Board Mount / DC DC Converters
Description CONV DC/DC 1.8V 3A HZ 10-SIP
PDF
/
Inventory: 965
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Technical

Trim/Adjustable Output YES
Output Current 3A
Output Power 5.4W
Nominal Input Voltage 48V
Input Voltage-Nom 48V
Voltage - Input (Min) 36V
Max Output Current 3A
Output Voltage 1.8V
Voltage - Input (Max) 75V
Voltage - Isolation 1.5kV
Efficiency 73%
Number of Outputs 1
Pin Count 10
Base Part Number PT4221
Terminal Pitch 2.54mm
Number of Functions 1
Terminal Position SINGLE
Technology HYBRID
Max Power Dissipation 5.4W
Power Rating 5.4W
Subcategory Other Analog ICs
Power (Watts) 10W
Applications ITE (Commercial)
Type Isolated Module
ECCN Code EAR99
Number of Terminations 10
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Feature UVLO
Series Excalibur? PT4220 (10W)
Packaging Tray
Operating Temperature -40°C~85°C

Dimensions

Height 7.87mm
Length 50.8mm
Width 25.9mm

Compliance

Radiation Hardening No
RoHS Status ROHS3 Compliant
Lead Free Contains Lead

Physical

Number of Pins 10
Package / Case 10-SIP Module
Mounting Type Through Hole, Right Angle
Mount Through Hole
