PT4144A
RoHS
RoHS compliant
RoHS compliantPackage 6-DIP Module
Category Power Supplies - Board Mount / DC DC Converters
Description
CONVERTER DC-DC 15V 1.3A HRZ
PDF
/
Inventory: 2759
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC Unknown
Radiation Hardening No
Dimensions
Height 8.382mm
Technical
Min Input Voltage (DC) 18V
Max Input Voltage (DC) 40V
Nominal Output Voltage 15V
Isolation Isolated
Max Output Power 20W
Nominal Input Voltage 24V
Current - Output 1 1.3A
Output Power 20W
Output Current 1.3A
Trim/Adjustable Output YES
Input Voltage-Nom 24V
Max Output Current 1.3A
Output Voltage 15V
Voltage - Isolation 1.5kV
Efficiency 86%
Number of Outputs 1
Pin Count 6
Base Part Number PT4144
Depth 37.59mm
Number of Functions 1
Terminal Form PIN/PEG
Terminal Position DUAL
Technology HYBRID
Max Power Dissipation 20W
Power Rating 20W
Subcategory Other Analog ICs
Applications ITE (Commercial)
Type Isolated Module
ECCN Code EAR99
Number of Terminations 6
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code yes
Size / Dimension 1.67Lx1.48W x 0.33 H 42.4mmx37.6mmx8.4mm
Series PT4140 (20W)
Packaging Tray
Operating Temperature -40°C~85°C
Physical
Number of Pins 6
Package / Case 6-DIP Module
Mounting Type Through Hole
Mount Through Hole
