PT4142C image
Favorite
PT4142C image
Favorite
RoHS
RoHS RoHS compliant
Package 6-SMD Module
Category Power Supplies - Board Mount / DC DC Converters
Description CONVERTER DC-DC 5V 4A HORZ SMD
PDF
/
Inventory: 5470
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

Lead Free Lead Free
Flammability Rating UL94 V-0
RoHS Status ROHS3 Compliant
REACH SVHC Unknown
Radiation Hardening No

Dimensions

Height 8.382mm

Technical

Min Input Voltage (DC) 18V
Max Input Voltage (DC) 40V
Nominal Output Voltage 5V
Isolation Isolated
Max Output Power 20W
Nominal Input Voltage 24V
Current - Output 1 4A
Output Power 20W
Output Current 4A
Trim/Adjustable Output YES
Input Voltage-Nom 24V
Max Output Current 4A
Output Voltage 5V
Voltage - Isolation 1.5kV
Efficiency 82%
Number of Outputs 1
Pin Count 6
Base Part Number PT4142
Depth 37.59mm
Number of Functions 1
Terminal Form GULL WING
Terminal Position DUAL
Technology HYBRID
Max Power Dissipation 20W
Power Rating 20W
Subcategory Other Analog ICs
Applications ITE (Commercial)
Type Isolated Module
ECCN Code EAR99
Number of Terminations 6
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code yes
Feature Remote On/Off, OTP, SCP, UVLO
Size / Dimension 1.73Lx1.52W x 0.33 H 43.9mmx38.6mmx8.5mm
Series PT4140 (20W)
Packaging Tray
Operating Temperature -40°C~85°C

Physical

Weight 23g
Number of Pins 6
Package / Case 6-SMD Module
Mounting Type Surface Mount
Mount Surface Mount
