PT3344N
RoHS
RoHS compliant
RoHS compliantPackage 19-SIP Module
Category Power Supplies - Board Mount / DC DC Converters
Description
Module DC-DC 24VIN 1-OUT 15V 2A 30W 19-Pin SIP Module
PDF
/
Buying Options
Total Price: USD $102.1
Unit Price: USD $102.096094
≥1 USD $102.096094
≥10 USD $96.317066
≥100 USD $90.865157
≥500 USD $85.721846
≥1000 USD $80.86967
Inventory: 3053
Minimum: 1
-
+
Technical Details
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case 19-SIP Module
Number of Pins 19
Technical
Operating Temperature -40°C~85°C
Packaging Tray
Series PT3340 (30W)
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 19
ECCN Code EAR99
Type Isolated Module
Applications ITE (Commercial)
Additional Feature UNDERVOLTAGE LOCKOUT
Subcategory Other Analog ICs
Power Rating 30W
Max Power Dissipation 30W
Technology HYBRID
Terminal Position SINGLE
Peak Reflow Temperature (Cel) NOT SPECIFIED
Number of Functions 1
Depth 12.95mm
Reach Compliance Code not_compliant
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Base Part Number PT3344
Pin Count 19
Number of Outputs 1
Qualification Status Not Qualified
Efficiency 85%
Voltage - Isolation 1.5kV
Voltage - Input (Max) 60V
Output Voltage 15V
Max Output Current 2A
Voltage - Output 1 15V
Voltage - Input (Min) 18V
Input Voltage-Nom 24V
Trim/Adjustable Output YES
Output Current 2A
Output Power 30W
Isolation Isolated
Dimensions
Length 76.7mm
Width 13.2mm
Compliance
RoHS Status ROHS3 Compliant
Lead Free Lead Free
